	Your Location： Home > Product > Voltage Sensor Style > F Series













            HEC-F6 Series





                Publish Time：2012/7/25   |    Click：882













          Electrical characteristics ：
          Type
          HEC500V-F6
          Rated Current
          0~±10mA
          Linear Range
          0～±14mA
          Output Current
          0~25mA
          Load resistance
          input current ±10mA,   100~350Ω    supply voltage ±15V
          input current ±14mA,   100~190Ω    supply voltage ±15V
                Accuracy
          ±0.6%
          Degree of Linearity
          ＜0.2%
          Turn Ratio
          2500:1000
          Offset Voltage
          ±0.1mA ±0.20mA(max)
          Temperature Drift
          ±0.20mA    ±0.64mA(max )   -10 ℃ ～ +70 ℃
          Response Time
          ＜40μS
          Power Supply
          ± 12V 、± 15V （± 5% ）
          Current Consumption
          10mA plus output current
           Isolation
          2.5KV DC
             Internal Resistance
          original coil 250Ω
          secondary coil 110Ω
          Operating Temperature Range
          0℃ ～ +70℃
          Storage Temperature Range
          -10 ℃ ～ +85 ℃
