Type

HEC4000-

C11

HEC5000-

C11

HEC6000-

C11

HEC7500-

C11

HEC9000-

C11

HEC10000-

C11

Rated Current

4000A

5000A

6000A

7500A

9000A

10000A

Output Voltage

4V 、 5V

Accuracy

±1%

Offset Voltage

±20mV

Hysteresis Error

±10mV

Temperature Drift

0.03%/ ℃

Response Time

＜ 10μS di/dt=50A/μS

Power Supply

± 12V 、± 15V （± 5% ）

Current Consumption 20mA

Isolation 6KV AC 50Hz/min

Operating Temperature Range -10 ℃ ～ +80 ℃

Storage Temperature Range -25 ℃ ～ +85 ℃
