	Your Location： Home > Product > Voltage Sensor Style > F Series













            HEC-F3 Series





                Publish Time：2012/7/25   |    Click：933













          Electrical characteristics ：
          Type
          HEC75mV…1000V-F3
          Rated Voltage
          75mV…1000V
          Output Voltage
          ±5V ?(0-20mA or 4-20mA output current)
          Accuracy
          ±0.2%
          Input Frequent Response
          0-20KHz
          Offset Voltage
          ＜10mV
          Temperature Drift
          0.02%/ ℃
          Response Time
          ＜ 1ms
          Power Supply
          ± 12V、± 24V （± 5% ）
          Current Consumption
          ±10mA
          Isolation
          2.5KV  DC
          Operating Temperature Range

                                                                    0 ℃ ～ +50 ℃
          Storage Temperature Range

                                                                 -10 ℃ ～ +70 ℃





















              Print || close










Prev：  HEC-F2 Series

Next： HEC-F3 Series(Single-phase)
