Type

HEC10000-

C14

HEC12000-

C14

HEC15000-

C14

HEC20000-

C14

HEC25000-

C14

HEC30000-

C14

Rated Current

±10000A

±12000A

±15000A

±20000A

±25000A

±.30000A

Linear Range

1.2 times of the maximum of measuring range

Output Voltage

±4V 、 5V? or 0-20mA/4-20mA output current

Accuracy

±1%

Offset Voltage

±20mV

Hysteresis Error

±10mV

Temperature Drift

0.025%/ ℃

Response Time

＜ 15μS  di/dt=50A/μS

Power Supply

± 12V 、± 15V （± 5% ）

Current Consumption    ±25mA

Isolation    3KV  AC  50Hz/min

Operating Temperature Range   -10 ℃ ～ +80 ℃

Storage Temperature Range    -25 ℃ ～ +85 ℃
