	Your Location： Home > Product > Open-loop Style > A Series













            HEC-A8 Series





                Publish Time：2012/7/25   |    Click：1196













          Electrical characteristics ：
          Type
          HEC100-A8
          HEC200-A8
          HEC300-A8
          HEC400-A8
          Rated Current
          100A
          200A
          300A
          400A
          Linear Range
          300A
          400A
          500A
          600A
          Output Voltage
          4V 、 5V
          Accuracy
          ±1%
          Offset Voltage
          ± 20mV
          Hysteresis Error
          ± 15mV
          Temperature Drift
          0.03%/ ℃
          0.025%/ ℃
          Response Time
          ＜ 7μS di/dt=50A/μS
          Power Supply
          ± 12V 、± 15V （± 5% ）
          Current Consumption 18mA
          Isolation 3KV AC 50Hz/min
          Operating Temperature Range -10 ℃ ～ +80 ℃
          Storage Temperature Range -25 ℃ ～ +85 ℃
